ACME Nut Plate For ACME Lead Screw TR8x2/TR8x4/TR8x8

Description

This ACME Nut Plate is a perfect fit for any integrated acme screw transmission project. It can fit into the hollow inserts of 20×40, 20×60 or 20×80 V-Slot.You can use self tapping screws to mount these into the end holes of V-Slot.

Features

• Easy to Mount on the ends of any V-Slot Linear Rail.Create an integrated transmission with any V-Slot Liner Rail
• Use in conjunction with the TR8x2 ,TR8x4,TR8x8 Metric Acme Lead Screw.



Specifications

• TR8*2: 2mm pitch, 2mm of linear movement per rotation. 8mm wide
• TR8*4: 2mm pitch, 4mm of linear movement per rotation. 8mm wide
• TR8*8: 2mm pitch, 8mm of linear movement per rotation. 8mm wide



• Model: NUTPLATE-TR8*2
• Pitch:2mm
• Lead:2mm
• Colour: Black
• Material: POM
• Size: 12.7 x 20 x 40 mm



• Model: NUTPLATE-TR8*4
• Pitch:2mm
• Lead:4mm
• Colour: Black
• Material: POM
• Size: 12.7 x 20 x 40 mm



• Model: NUTPLATE-TR8*8
• Pitch:2mm
• Lead:8mm
• Colour: Black
• Material: POM
• Size: 12.7 x 20 x 40 mm



Package Includes

• 1x Nut Plate (TR8*2/TR8*4/TR8*8 for choice)

---

Drawings show:

Picture show:

Please note: We sell to businesses for bulk order quantity please contact [email protected] for special distribution pricing.
