Description

Key Features

• Power Output: 1500W RMS / 3Ω, 8000W Peak / 3Ω
• Amplifier Type: Class D with DSP
• Bluetooth & App Control: Adjust volume, tuning, polarity, phase (0° to 180°), HPF, LPF, slope, EQ, no-signal standby, wake-up level, input level match, and select from four listening modes
• Inputs/Outputs: XLR input, RCA input, subwoofer output
• Cabinet: Solid MDF construction
• LCD Touch Screen: For easy controls
• Wireless Software Upgrades for continuous improvements

Tonewinner SW-D8000PRO Subwoofer Specifications

• Model: SW-D8000PRO
• Frequency Range: 12 – 220 Hz
• Drivers: Dual 15-inch drivers
• Power Supply: 110-115V~ (60Hz) / 220-230V~ (50Hz)

Power Output

• RMS Power: 1500W (3Ω)
• Peak Power: 8000W (3Ω)

Performance

• Max SPL (Peak, Music, 1m): 121 dB (C)
• Air Volume Displacement (Vd): 2.41 L/dm³

Weights

• Gross Weight: Approx. 211.6 lbs per unit
• Net Weight: Approx. 187.4 lbs per unit

Dimensions

• Subwoofer Dimensions (W × D × H): 930 × 650 × 612 mm
• Package Dimensions (W × D × H): 1085 × 800 × 730 mm

Accessories

• User Manual
• Power Cord
• Certificate of Qualification
